ST to SC Multimode OM4+ Ultra Fiber Cable
The iFiber Optix ST to LC Multimode OM4+ Ultra Fiber Cable is a high-performance optical fiber solution built for fast, dependable, medium-distance data transmission — delivering solid signal integrity, low latency, and reliable performance in data centers, enterprise LANs, and telecom systems.
Designed for modern high-speed networks, OM4+ fiber gives you the bandwidth and reach needed for 40G and 100G infrastructure while keeping your installation clean, efficient, and future-ready.
ST to LC Multimode OM4+ Ultra Fiber Cable
An ST to LC Multimode OM4 fiber cable is a versatile optical fiber cable designed for medium-distance data transmission with strong bandwidth performance. OM4+ multimode fiber supports laser-optimized transmission, making it a dependable option for 10G, 40G, and 100G Ethernet applications.
The ST connector brings a sturdy bayonet-style lock, while the LC connector offers a compact small-form-factor design. Together they provide a practical mixed-interface solution for labs, telecom rooms, legacy systems, and high-density network environments.
Performance Specifications
All iFiber Optix ST-LC OM4+ assemblies are manufactured and tested to meet or exceed the following optical and mechanical performance specifications.
| Insertion Loss | < 0.3 dB |
| Return Loss | ≥ 20 dB |
| Attenuation (850 nm) | ≤ 3.0 dB/km |
| Bandwidth (850 nm) | 4700 MHz·km (EMB) |
| Temperature Range | -40°C to +85°C |
| Connector Type | ST to LC Duplex |
| Fiber Core / Cladding | 50 / 125µm |
| Jacket Color | Violet / OM4+ |
| Jacket Options | OFNR, OFNP (Plenum), LSZH |
| Standard | TIA-492AAAD, IEC 60793-2-10 |
Key Features
- High-Speed Data Transmission OM4+ fiber supports modern high-speed data rates, making it a dependable choice for data centers, SANs, and enterprise LANs that need 10G, 40G, or 100G Ethernet.
- Extended Reach OM4+ fibers support 10G links up to 550 meters and 40/100G links up to 150 meters, giving you strong reach for demanding network layouts.
- Low Insertion Loss & Stable Performance LC and ST connectors provide low insertion loss (<0.3 dB) and stable signal delivery, helping reduce errors and preserve transmission quality.
- Mix of Secure and Compact Connectivity The ST connector gives you a rugged twist-lock style connection, while the LC connector keeps the footprint small and clean on the equipment side.
- Durable & Reliable Construction Built with quality materials, these cables are made to handle frequent handling and keep performing in busy network environments.
- Future-Ready Fiber Path OM4+ gives you a solid path for future upgrades, keeping your infrastructure ready for higher-speed network expansion.
Ideal Applications
ST to LC Multimode OM4+ cables are a practical fit for network spaces where mixed connector types and high-speed transmission both matter.
Data Centers
Supports high-speed links between switches, servers, and storage gear in dense environments.
Local Area Networks
Ideal for enterprise LAN runs where reliable performance and interface flexibility are important.
Telecom Systems
Useful in telecom rooms and distribution spaces that mix legacy and modern connector styles.
Storage Area Networks
Helps support high-bandwidth storage traffic where low latency and stable links are essential.
Test & Measurement
A smart choice for labs, demo setups, and testing environments that need dependable fiber patching.
Custom Fiber Builds
Available in custom lengths and configurations for projects that need a specific setup.
How to Choose the Right OM4 Configuration
Use these quick checks to match the right ST to LC OM4+ cable to your deployment.
Confirm Distance & Bandwidth
OM4+ supports strong medium-distance performance for high-speed links. If your run needs longer reach or future long-haul growth, singlemode OS2 may be the better fit.
Select Cable Length
Choose the length that matches your route cleanly so you avoid excess slack and keep the installation organized.
Choose Jacket Type
Use OFNR for standard spaces, OFNP for plenum-rated areas, and LSZH where low-smoke, halogen-free cable is preferred.
Match the Connector Layout
ST on one side and LC on the other make this assembly a good option when you need to bridge older and newer equipment without compromising performance.
Advantages Over Previous Fiber Types
- Higher Bandwidth & Speed OM4+ gives you better high-speed headroom than older multimode options, helping your network keep up with growing traffic.
- Extended Distance It offers stronger medium-distance reach, making it a practical choice for larger rooms, telecom spaces, and campus-style deployments.
- Future-Ready Solution The OM4+ platform is built for modern Ethernet needs and can keep pace as network speeds continue to climb.
- Mixed-Connector Flexibility ST to LC gives you a simple way to connect different equipment styles without forcing a full infrastructure change.
- Cost-Effective Performance OM4+ multimode provides a strong balance of performance and cost for medium-range applications where singlemode may be more than you need.
Why Choose iFiber Optix?
- Quality Assurance Every ST-LC OM4+ assembly is built for dependable performance and factory tested before shipment to help ensure consistency across every cable.
- Custom Configurations Available Custom cable lengths, jacket types, and bulk quantities are available for projects that need a more specific fit.
- Built for Real-World Deployments This cable is designed to work in demanding network environments where stable performance and flexible connectivity matter.
Request Information
Ready to spec ST-LC OM4+ cables for your next deployment? Our team can help with custom lengths, jacket selection, and bulk pricing.
